FLEXI-STRAP STANDARD DUTY 122-135mm

The closure fixing is manufactured from grade A4-70 stainless steel. The standard duty (SDL) version is paired with the Vulcan+™ and the heavy-duty (HDL) version is paired with Emperor™. Non-standard strap designs can be supplied upon request.

SKU: EPFS122-135SDL Category:

Description

Flexi-strap™ intermediate strap has been designed, developed, tested and manufactured in accordance with IEC 61914.
Flexi-strap™ is available in a range of sizes with range taking ability to suit cables in trefoil formation or bundles of cables. The strap of the cleat is manufactured from corrosion-resistant grade 316L stainless steel, the cable is supported by a liner manufactured from a low smoke and fume zero halogen (LSOH) material.

Additional information

Short Circuit Test @ 600mm (kA)

121.8

Cable Range Min Dia. mm)

122

Cable Range Max Dia. mm)

135

Weight

532
